What kind of accessories should installed on fermenters?
In the last article we mentioned that most of the modern micro breweries with auto controlling, it mostly because of the advanced parts used in the fermentation tanks. Today we will do more introduction for you about the accessories must needed for the fermentation tanks.
1.Positive pressure valve
We all know the fermenter must be pressure resistance, but in case some dangerous when the tank pressure rise, so generally there should be positive pressure valve on the top of the fermentation tanks.
2.Negative pressure valve
The conical tanks are sensitive about negative pressure, their shape may be changed even with tiny negative pressure. The air volume inside of the tank may be greatly changed even under very small temperature changes, so it is more dangerous of the negative pressure compared with positive pressure.
3.CIP cleaning unit
The CIP is vital component of the conical fermenter, which will ensure the safety beer brewing and sanitary management. The CIP spray ball should connected well with the piping on the top of the tank, then the top inside of the tank can also be cleaned very well.
4.Thermometer and thermowell
We know it will need exactly temperature testing and controlling during fermentation, so the thermometer is also obbligato. For some commercial fermentation tanks, it is available for installing two thermowell on the top 1/3 and bottom 1/3, as the natural convection inside of the tank will cause temperature difference.
5.Pressure gauge
It is used for checking the inside pressure.
Tiantai pressure gauge with dual-display: bar and psi.
6.Sample valve
The sample valve must be sanitary during usage.
Tiantai beer fermenters adopted Perlick style sample valve without thread inside, which will avoid the hidden of bacteria.
7.Manhole
Sometime we should do overhaul for the fermentation tanks, the manhole now is necessary.
8.Hopping port
Now all of our beer fermentation tanks with dry hopping port.
Welcome to share with us if you have any special ideas, our technical team will examine and customize for you accordingly.
