The cooling jacket and temperature sensor for fermentation tanks
- Nov 10, 2017
- helen
- 7998
- fermentation tanks
The cooling jacket and temperature sensor for fermentation tanks
1.Cooling Jacket
Cylindrical conical fermenter cooling jacket normally have 2 or 3 cooling zones. Tanks area have 2 or 3 cooling zones, cone area have one cooling zone.
The location of cooling jacket: Top of cooling jacket on tanks shell normally located below liquid level 15cm, top of cooling jacket under the tanks shell should locate below 50% liquid level 15cm. The cooling jacket on cone should near bottom cone as far as possible.
2.Temperature sensor
According to brewing process demands, open different cooling jacket to cooling the beer, and choose right temperature sensor to get beer real temperature. Normally can set two temperature sensor:Lower part temperature senor locate in the bottom of column, higher temperature sensor under the top cooling jacket.
The using situation for cooling jacket and temperature sensor as follows:
Tanks Function Cooling Jacket Uses Temperature Sensor Uses
Control temperature during fermetation
Diacetyl reduction temperature to 3℃
Cooling further to below 3℃
Storage stage Two cooling zones on column
Two cooling zones on column
Cone and bottom cooling jacket
Cone cooling jacket Bottom temperature sensor
Bottom temperature sensor
Top temperature sensor
Top temperature sensor
Edited by Derrick
Sales Manager in Tiantai Company
Email:[email protected]
