Brewery Equipments
5000L Whirlpool Tun
- Mar 09, 2016
- Ray Lee
- 0
- brewing whirlpool
5000L Whirlpool Tun
Description
At the end of the boil, the hopped wort settles to clarify in a vessel called a "whirlpool" where there is a tangential inlet of wort. Thus, a vortex is formed when the wort is infused along the arc inside surface, so that the more solid particles in the wort are separated out. Whirlpool can happen in the kettle because there is no obstacle inside the kettle.
Standard Configuration
Function: Wort boiling, whirlpool
Tank Capacity:5000L (+20% Headspace minimum)
Dimention: Φ2200mmx3800mm
Interior Shell: SUS304 full welded; TH=4mm
Exterior Shell:SUS304 full welded; TH=2mm
100% TIG welding with pure argon gas shield
Interior Finish: Overall polishing to 0.4~0.6 μm without dead corner
Insulation: Rock wool; TH=80mm
Heating:No
Steam Jacket: No
Dished top and sloped bottom
Stainless steel top mounted manway
360° coverage CIP spraying ball
Tangential whirlpool inlet
4pcs completely SUS304 heavy duty legs with leveling pad
Description
At the end of the boil, the hopped wort settles to clarify in a vessel called a "whirlpool" where there is a tangential inlet of wort. Thus, a vortex is formed when the wort is infused along the arc inside surface, so that the more solid particles in the wort are separated out. Whirlpool can happen in the kettle because there is no obstacle inside the kettle.
Standard Configuration
Function: Wort boiling, whirlpool
Tank Capacity:5000L (+20% Headspace minimum)
Dimention: Φ2200mmx3800mm
Interior Shell: SUS304 full welded; TH=4mm
Exterior Shell:SUS304 full welded; TH=2mm
100% TIG welding with pure argon gas shield
Interior Finish: Overall polishing to 0.4~0.6 μm without dead corner
Insulation: Rock wool; TH=80mm
Heating:No
Steam Jacket: No
Dished top and sloped bottom
Stainless steel top mounted manway
360° coverage CIP spraying ball
Tangential whirlpool inlet
4pcs completely SUS304 heavy duty legs with leveling pad
